Satcom Solutions & Avionics
Discover industry-leading satellite communication (Satcom) hardware and avionic accessories for manned and unmanned aviation.
Satellite Communications and Data Acquisition for Aircraft
Gain broadband Satcom speeds and capabilities essential to your operation. Experience Iridium Certus for fixed-wing, rotorcraft, and unmanned aviation segments. To learn more about SKYTRAC Iridium Certus terminals, please download one of our product brochures or contact sales@skytrac.ca.
BROADBAND SATCOM
Up to 704 Kbps of Bandwidth
SDL-350™ SERIES 2
Broadband Iridium Certus Satellite Communications Terminal
BROADBAND SATCOM
Up to 704 Kbps of Bandwidth
IMS-350™
Lightweight Broadband
Iridium Certus Satellite Communications Terminal
SkyLink 7100™
Midband Iridium Certus Satellite Communications Terminal
MIDBAND SATCOM
Up to 88 Kbps of Bandwidth
DLS-100™
Lightweight Midband
Iridium Certus Satellite Communications Terminal
NARROWBAND SATCOM
2.4 Kbps of Bandwidth
ISAT-200A™ SERIES 7
Iridium Narrowband Satellite Communications Terminal
Global Aeronautical Distress and Safety Systems
ADT-5000™
Autonomous Distress Tracking System for GADSS Compliance
Satcom Accessories
Multi-Touch Controller
(MTC-100)
SKYTRAC’s MTC-100 is a cockpit/cabin interface for air and ground crews. The system includes customizable screens for mission-critical applications and NVIS compliance.
Inflight Cameras
(CRU-200)
Discreetly record hours of high-resolution cockpit audio-visuals to enhance your flight data monitoring program. Pair with multiple lenses in any combination.
External Cellular & Wi-Fi Antenna
The optional small footprint external cellular/Wi-Fi antenna provides in-flight cellular connectivity and post-flight Wi-Fi/Cellular downloading capability.
Internal Wi-Fi Hotspot Antenna
The internal Wi-Fi hotspot antenna, designed for the aircraft cockpit or cabin, connects onboard devices wirelessly to the SDL-350 for broadband data connectivity.
Iridium
Antennas
Iridium Antennas
Phased Array, Hight Gain Antenna (HGA)
Date Rates:
352/704 Kbps
(Tx/Rx)
Interface:
Single Coax (<10 meters)
Dimensions:
5.00” x 2.20” x 0.72”
(19.94cm x 7.62cm x 4.95cm)
Weight:
1.36kg (3.00 lbs.)
Active Low Gain Antenna (A-LGA)
Date Rates:
176 Kbps
(Bi-directional)
Interface:
Single Coax (<2 meters)
Dimensions:
9.10” x 4.34” x 2.25”
(23.10cm x 11.02cm x 5.72cm)
Weight:
1.36 kg (3.00 lbs.)
Dual Element / GPS Antenna
Date Rates:
2.4 Kbps for GPS, PTT, SBD
(Bi-directional)
Interface:
Single Coax (<2 meters)
Dimensions:
5.00” x 2.20” x 0.72”
(19.94cm x 7.62cm x 4.95cm)
Weight:
240 g (8.5 oz.)
Passive Low Gain Antenna (P-LGA)
Date Rates
176 Kbps
(Bi-Directional)
Interface
Single Coax (<2 meters)
Dimensions
3.5” diameter (8.89cm)
Weight
141g (5oz.)
